CAT6 RJ45 Blue Keystone Jack EZ IC1078L6BL

CAT6 RJ45 Keystone Jack for EZ® Style

Jack Style: EZ
  • CAT6A RJ45 Keystone Jack UTP HD Style IC1078GAWH
  • CAT6 RJ45 White Keystone Jack EZ IC1078L6WH
Performance: CAT6

Country of Origin (subject to change): Taiwan

Warning SymbolCalifornia Prop 65 Warning


ICC’s EZ Category 6 modular jacks, RJ-45 keystone jacks, is 8-position 8-conductor (8P8C) is engineered to provide superior performance and reliability, supporting Gigabit Ethernet applications and beyond. The advanced printed circuit board design is tuned to provide optimum signal quality with maximum headroom, allowing it to exceed TIA Category 6 performance standards. It offers superior signal quality and noise reduction due to its enhanced Near-End and Far-End Crosstalk cancellation and minimum return losses. The EZ connector’s flat back IDC construction offers faster installation through its straight through in-line termination design and one piece snap-on termination cap.


  • CAT6 rated connectors provide excellent performance for data networks requiring max speed and bandwidth.
  • Supports Power over Ethernet (PoE++) Type 4; up to 100 Watts.
  • PCB technology provides maximum performance and superior signal quality.
  • Enhanced crosstalk cancellation reduces return loss and improves performance by rejecting noise and unwanted signals.
  • Designed with in-line 110 IDC, in-sequence termination reducing termination time.
  • Terminate with 110 punch down tool or JackEasy Termination Tool.
  • One piece termination cap allows for a quick and easy termination.
  • Includes an integrated TIA-568A/B color wiring diagram.
  • Backward compatible with all lower rated category components.
  • Works with all Work Area Outlets faceplates, inserts, surface mount boxes.
  • Used with ICC Category 6 patch cords.
  • Exceeds ANSI/TIA-568-C requirements for permanent performances.
  • UL 1863 Compliant.



Termination Cap: PC, UL 94V-0

Housing: ABS, UL 94V-0


Current Rating: 1.5 amps

Insulation Resistance: 500 mohms min

Contact Resistance: 20 mohms max

DC Resistance: 0.1 ohms max


Plug Insertion Life: 750 cycles min

Plug and Jack Contact Force: 100-gram min using FCC approved plug

Plug Retention Force: 50N (11lbs) for 60s ±5s

Temperature: -40° to 150° F (-40° to 68° C)


Jack Wiring: 50 microinches of Gold over 100 microinches of Nickel

Connector: Insulation Displacement Connector (IDC); accepts 22-24 AWG solid wire


Colors XX: AL-Almond, BK-Black, BL-Blue, GN-Green, GY-Gray, IV-Ivory, OR-Orange, PR-Purple, RD-Red, WH-White, YL-Yellow
