3.5 mm Stereo Audio Coupler Module with Push-pin

SKU: N/A Categories: , ,

Country of Origin: China

Warning SymbolCalifornia Prop 65 Warning


The 3.5mm (1/8″) modular jack allows users to connect to headphones, microphones, infrared repeater devices, sound cards, and mp3 players from remote locations. The keystone jacks may be used in two or three conductor applications. Rear push-pin design allows for simple, fast connections to UTP cable or any 22-24 AWG wire. This device is intended to provide easy installation of female 3.5mm modular jacks into any wallplates and Decorex inserts.


  • Connect to headphones, microphones, sound cards, and MP3 player.
  • Fast fingertip insertion.
  • Capable of UTP wiring in size of 22-24 AWG for simple connection.
  • Works with all ICC outlet faceplates.


Housing: ABS
Connector Body: Phosphor bronze
Plating: Nickel
Rating: DC 50V 0.5A
Contact resistance: 50m Ohm max
Insulation resistance: 100m Ohm min
Insertion force: 0.3Kgf-3Kgf
Extraction force: 0.3Kgf-3Kgf
Color XX: AL-Almond, BL-Black, IV-Ivory, WH-White
